Description
The Mitre Saw has integrated positive mitre stops at 15°, 22.5°, 30°, 45° and a quick release mitre mechanism up to 50°. The head lock function allows the head to be fixed, restricting the traverse function for trim applications and for ease of transportation.
It has a sliding left hand fence with measuring scale for improved material support and management, and its XPS shadow line cut indicator provides fast accurate alignment of the blade while illuminating the work piece for increased productivity.
The DWS778 has a dust extraction system specifically designed to meet the needs of the professional user in heavy use applications, providing protection from airborn dust particles to minimise health risks over long periods.
Supplied with: 1 x TCT 250mm Blade 30mm Bore, 1 x Clamp and 1 x Hexagon Key.
Specifications:
Input Power: 1,850W.
No Load Speed: 4,300/min.
Blade: 250 x 30mm Bore.
Capacity (mm): 90°/90°: 305x85, 90°/45°: 305x58, 45°/90°: 215x85, 45°/45°: 215x48.
Mitre Capacity (Right/Lef): 50° / 50°.
Bevel Capacity: 48°.
Weight: 17.2kg.
DEWALT DWS778 250mm Mitre Saw 1850 Watt in the 110 Volt Version.
Specifications
Catalog Page Number
461
Blade Diameter x Bore
250 x 30mm
Brand
Dewalt
Categories
Power Tools
Category
Saws
Country Of Origin
ITALY
Dimensions
570x472x594mm
Form
Corded Mitre Saw
Input Power
1850W
Manufacturer
Dewalt
Type
Saws
Voltage
110V
Weight
21.004kg
